Film Blowing Machine Set
| Payment Terms: | T/T |
| Place of Origin: | Zhejiang, China (Mainland) |
|
|
| Add to My Favorites | |
| HiSupplier Escrow |
Product Detail
The cylinders and the screw stems of model SJ-45-50 extruder are made of high-quality alloy steel with optimum hardness.
Name: HDPE-LDPE Dual-Purpose Film Blowing Machine Set A Type
Characteristics:
The cylinders and the screw stems of model SJ-45-50 extruder are made of high-quality alloy steel with optimum hardness and strong corrosion resistance after precision finishing and nitrogen treatment. FM-600 auxiliary machine can be freely adjusted within the limits of 700mm according to the technological requirements of different materials, and is fitted with a plug-in plate mechanism for making vest bag. The double-rolling and double-cutting coiling unit adopts torque motor to keep proper tension and make even and roll-changing easy.
The cylinders and the screw stems of model SJ-45-50 extruder are made of high-quality alloy steel with optimum hardness and strong corrosion resistance after precision finishing and nitrogen treatment. FM-600 auxiliary machine can be freely adjusted within the limits of 700mm according to the technological requirements of different materials, and is fitted with a plug-in plate mechanism for making vest bag. The double-rolling and double-cutting coiling unit adopts torque motor to keep proper tension and make even and roll-changing easy.
USE:
It is used for blowing the various plastic film of low density polyethylene(LDPE), high density polyethylene(HDPE) and linear low density polyethylene (LLDPE) etc, Which are widely used for packing food, fruit, garments, textile, barbate bag and vest bag other civil and industrial products, etc and for vest bag.
It is used for blowing the various plastic film of low density polyethylene(LDPE), high density polyethylene(HDPE) and linear low density polyethylene (LLDPE) etc, Which are widely used for packing food, fruit, garments, textile, barbate bag and vest bag other civil and industrial products, etc and for vest bag.
Model | SJ-45/FM650 | SJ-50/FM850 |
Screw Diameter | 45mm | 50mm |
Screw Ratio | L/D28:1 | L/D28:1 |
Screw Speed | 10-100r/min | 10-100r/min |
Power of Main Motor | 11KW | 15KW |
Max. Extrusion output | 35kg /h | 50kg /h |
Max. Folding Width of Film | 600mm | 800mm |
Single-sided Thickness of Film | 0.006 -0.10mm | 0.006 -0.10mm |
Lifting Range of Auxiliary Machine | 700mm | 700mm |
Total Power | 22Kw | 28Kw |
Weight of Machine | 2200kg | 2600kg |
Overall Dimensions( L × W × H ) | 4000×2000× 2800mm | 4600×2300× 3800mm |
